Large Round Canopy
![ECLP3 Series]()
Large Round Canopy
Available:
In Stock
The PRSC series is a Large Round Canopy style fixture designed to replace existing HID and Fluorescent systems, both indoor and outdoor. An attractive round housing provides even illumination, and can be surface mounted or pendant hung to achieve the style you’re looking for.
$0.00
Applications:
- Schools
- Shopping Centers
- Garages
- Any Public Building
- Surge Protection
- Photocell
Applications:
- Schools
- Shopping Centers
- Garages
- Any Public Building
- Surge Protection
- Photocell
Housing: Die cast aluminum housing, integral heat sinking, powdercoat finish over a chromate conversion coating. Photocell adaptable.
Lens: Clear or LumaLens opal lens to seal LED array.
Mounting: Included Easy-Hang bracket fits standard 102mm electrical box, allowing one person installation.
LED: Array Lumens: 24,553 Delivered Lumens:5000K-17,360 / 4000K-16,188 / 3000K-15,624 CRI: 80+ CCT: 5000K Rated Life: 50,000 Hours 5-Year Warranty Aluminum Boards
Wattage: Array: 176w, System: 186w
Driver: Electronic Driver, 120-277V, 50/60Hz Dimmable Driver
Listings & Ratings: IP67 Operating Temperatures: -40°C to +50°C
