ECLP Series
![Large Round Canopy]()
ECLP Series
Available:
In Stock
The ECLP series LED canopy light is an ideal solution for illuminating parking garages, storage areas, stairwells, and other applications requiring low-profile luminaire that can be surface- or pendant-mounted. With a die cast aluminum housing and a polycarbonate lens, the ECLP will stand up to many years of punishing environmental conditions. High-efficacy, long-life LEDs provide both energy and maintenance cost savings compared to traditional canopy lights with HID, fluorescent or incandescent lamps.
$0.00
Specifications
- Available in 5000k (cool white) color temperature.
- Long-life LEDs provide a minimum of 60,000 hours of operation with at least 70% of initial lumen output (L70).
- ECLP-45W delivers 4,948 lumens and 112 lumens per watt (LPW), and ECLP-80W delivers 9,548 lumens and 120 LPW.
- Universal 120-277 AC voltage (50-60Hz) is standard.
- 0-10vdc dimming capability is standard. Power factor > 0.90. Total harmonic distortion < 20%. Color rendering index > 80.
- 10kV surge protector is standard.
- Die cast aluminum housing with durable, dark bronze, powder coat paint.
- Polycarbonate lens.
- Removable, threaded plugs for side attachment of ½” rigid electrical conduit. Easy installation in new construction or retrofit. 5-year warranty on all electronics and housing.
- Optional PIR (passive infrared) occupancy sensors are available (contact factory for details).
- cULus listed for wet locations (-40°C to 40°C / -40°F to 104°F).
- IP65 rated. Complies with FCC Part 15, class B.
Specifications
- Available in 5000k (cool white) color temperature.
- Long-life LEDs provide a minimum of 60,000 hours of operation with at least 70% of initial lumen output (L70).
- ECLP-45W delivers 4,948 lumens and 112 lumens per watt (LPW), and ECLP-80W delivers 9,548 lumens and 120 LPW.
- Universal 120-277 AC voltage (50-60Hz) is standard.
- 0-10vdc dimming capability is standard. Power factor > 0.90. Total harmonic distortion < 20%. Color rendering index > 80.
- 10kV surge protector is standard.
- Die cast aluminum housing with durable, dark bronze, powder coat paint.
- Polycarbonate lens.
- Removable, threaded plugs for side attachment of ½” rigid electrical conduit. Easy installation in new construction or retrofit. 5-year warranty on all electronics and housing.
- Optional PIR (passive infrared) occupancy sensors are available (contact factory for details).
- cULus listed for wet locations (-40°C to 40°C / -40°F to 104°F).
- IP65 rated. Complies with FCC Part 15, class B.
