Exterior Rounded Sconce (NHL-CS)
The NHL-CS cut-off architectural wall luminaire is available with an IES Type III distribution designed to replace HID lighting systems from 150w to 250 MH or HPS. Typical wall mounted lighting applications include retail centers, industrial parks, schools and universities, public transit and airports, office buildings and medical facilities. Mounting heights of 12 to 20 feet can be used based on light level and uniformity requirements.
- Product SKU: NHL-CS
- Category: Decorative Site, Outdoor, Sconce
CSA: Listed for Wet Locations Meets Dark Sky Requirements. LM-79 Report Available on Select Models.
Options: 2.5KV Surge Protection, Custom Colors Available Upon Request.
CSA: Listed for Wet Locations Meets Dark Sky Requirements. LM-79 Report Available on Select Models.
Options: 2.5KV Surge Protection, Custom Colors Available Upon Request.
Housing: Die Cast Aluminum Housing with Full Cutoff Front Frame, Textured Architectural Bronze Powdercoat Finish Over a Chromate Conversion Coating
Lens: Clear Glass Lens
Mounting: Mount Over a 4 inch Recessed Outlet Box, Includes Easy-Hang Wall Mounting Plate.
LED System: Array Lumens: 5,445 Delivered Lumens: 5000K- 5042 / 4000K-4613 CRI: 80+ CCT: 5000K/4000K
Rated Life: 50,000 Hours, 5-Year Warranty, Aluminum Boards
Wattage: Array: 46.5w, System: 52w
Driver: Electronic Driver, 120-277V, 50/60Hz or 347/480V, 50/60Hz; Dimmable Driver
Lifespan: 393,000-hour LED Lifespan based on L70 Calculations
