HDCVT2 & HDCVT4
HDCVT2 & HDCVT4
Available:
In Stock
The NHL-HDCVT 2' Class 1, Division 2 Hazardous Location 2' series wall, pendant and ceiling mount luminaire is available with clear or opal lenses and open door frame designed to replace HID lighting systems from 175w to 250w MH or HPS. Typical Lighting applications include retail centers, industrial parks, schools & universities, public transit and airports, office buildings and medical facilities. NSF certification meets the requirements for Food Processing Facilities. Mounting heights of 12 to 25 feet can be used based on light level and uniformity requirements.
The NHL-HDCVT4 Class 1, Division 2 Hazardous Location 4' series wall, pendant and ceiling mount luminaire is available with clear or opal lenses and open door frame designed to replace HID lighting systems up to 400w MH or HPS. Typical lighting applications include retail centers, industrial parks, schools and universities, public transit and airports, office buildings and medical facilities. NSF certification meets the requirements for Food Processing Facilities. Mounting heights of 18 to 30 feet can be used based on light level and uniformity requirements.
The NHL-HDCVT4 Class 1, Division 2 Hazardous Location 4' series wall, pendant and ceiling mount luminaire is available with clear or opal lenses and open door frame designed to replace HID lighting systems up to 400w MH or HPS. Typical lighting applications include retail centers, industrial parks, schools and universities, public transit and airports, office buildings and medical facilities. NSF certification meets the requirements for Food Processing Facilities. Mounting heights of 18 to 30 feet can be used based on light level and uniformity requirements.
- Product SKU: NHL-HDCVT2, NHL-HDCVT4
- Category: Hazardous, Specialty
$0.00
Applications:
Typical lighting applications include industrial facilities, oil, gas, painting facilities, and auto service facilities. Mounting heights of 12 to 25 feet for the HDCVT2 and 18 to 30 feet for the HDCVT4 can be used based on light level and uniformity requirements.
Applications:
Typical lighting applications include industrial facilities, oil, gas, painting facilities, and auto service facilities. Mounting heights of 12 to 25 feet for the HDCVT2 and 18 to 30 feet for the HDCVT4 can be used based on light level and uniformity requirements.
- Housing: Heavy-Duty Die CastAluminum Housing and Top Frame, with 1/2” Tapped Coin Plug Openings for Wiring Entrance Conduits.
- Listing & Ratings: ETL Listed for Hazardous Locations Per UL844 as Follows: Class 1, Division 2 GroupsA, B, C, D; T4 Temperature Rating Suitable for Wet Locations, IP66 Sealed LED Compartment.
- Finish: Powdercoat Finish Over a Chromate Conversion Coating.
- Lens: Clear Polycarbonate or SoftLED LumaLens Opal Polycarbonate Vandal-Resistant Lens
- Mounting Options: Mount with Stainless SteelAdjustable Bracket or Yoke. Rated for 6 #12AWG 90°C for Through Wiring.
- Wattage: 47w: Array: 47w, System: 57.8w; (175w HID Equivalent) 66w: Array: 66w, System: 77.3w; (250w HID Equivalent)
- Driver: Electronic Driver, 120-277V, 50/60Hz or 347-480V, 50/60Hz; Less Than 20% THD and PF>0.90. Standard Internal Surge Protection 6kV. 0-10V Dimming Standard for a Dimming Range of 100% to 10%; Dimming Source Current is 150 Microamps.
- Warranty: 5-Year Warranty for -25°C to +40°C Environment.
- Housing: Heavy-Duty Die CastAluminum Housing and Top Frame, with 1/2” Tapped Coin Plug Openings for Wiring Entrance Conduits.
- Listing & Ratings: ETL Listed for Hazardous Locations Per UL844 as Follows: Class 1, Division 2 GroupsA, B, C, D; T4 Temperature Rating Suitable for Wet Locations, IP66 Sealed LED Compartment
- Finish: Powdercoat Finish Over a Chromate Conversion Coating.
- Lens: Clear Polycarbonate or SoftLED LumaLens Opal Polycarbonate Vandal-Resistant Lens
- Mounting Options: Mount with Stainless SteelAdjustable Bracket or Yoke. Rated for 6 #12AWG 90°C for Through Wiring.
- Wattage: 112w: Array: 112w, System: 126w; (250w HID Equivalent) 136w: Array: 136w, System: 152w; (400w HID Equivalent)
- Driver: Electronic Driver, 120-277V, 50/60Hz or 347-480V, 50/60Hz; Less Than 20% THD and PF>0.90. Standard Internal Surge Protection 6kV. 0-10V Dimming Standard for a Dimming Range of 100% to 10%; Dimming Source Current is 150 Microamps.
- Warranty: 5-Year Warranty for -25°C to +40°C Environment.
