NHL-ESW
The ESW is an economy LED Stairwell Fixture. Occupancy sensor and emergency batteries are optional, but required by most city or township codes. Filed selectable for both CCT and wattage with three different lumen outputs and three different color temperatures, the NHL-ESW can safely light up an stairwell.
- Category: Interior, Surface Mount Wall
- ▪ Field selectable 3500k (warm/neutral white), 4000k (neutral white), and 5000k (cool white) color temperatures.*
- ▪ Long-life LEDs provide 190,000 hours of operation with at least 70% of initial lumen output (L70), and 58,000 hours with at least 90% of initial lumen output (L90).**
- ▪ Selectable lumen outputs range from 4200 nominal lumens to 6000 nominal lumens.
- ▪ Universal 120-277 AC voltage (50-60Hz) is standard.
- ▪ 0-10vdc dimming drivers are standard.
- ▪ Power factor > 0.90.
- ▪ Total harmonic distortion < 20%.
- ▪ Color rendering index > 80.
- ▪ Painted steel housing and PMMA (polymethyl methacrylate) frosted lenses are standard.
- ▪ Optional occupancy dimming sensor specifically designed to sense motion and illuminate both up and down stairwells (fig 1).
- ▪ Easy installation in new construction or retrofit.
- ▪ cULus listed for damp locations ambient temperatures from
- - 20°C to 50°C (-4°F to 122°F).
- ▪ cULus 1598 and 924 listed.*
- ▪ DLC 5.1 premium approved.
- ▪ Complies with FCC Part 15, class A.
- ▪ Complies with IEEE C.62.41-1991, input transient protection (2.0kV).
- ▪ 5-year warranty of all electronics and housing.
- ▪ Surface Mounting
- * UL 924 listed when used with emergency drivers.
- ▪ Field selectable 3500k (warm/neutral white), 4000k (neutral white), and 5000k (cool white) color temperatures.*
- ▪ Long-life LEDs provide 190,000 hours of operation with at least 70% of initial lumen output (L70), and 58,000 hours with at least 90% of initial lumen output (L90).**
- ▪ Selectable lumen outputs range from 4200 nominal lumens to 6000 nominal lumens.
- ▪ Universal 120-277 AC voltage (50-60Hz) is standard.
- ▪ 0-10vdc dimming drivers are standard.
- ▪ Power factor > 0.90.
- ▪ Total harmonic distortion < 20%.
- ▪ Color rendering index > 80.
- ▪ Painted steel housing and PMMA (polymethyl methacrylate) frosted lenses are standard.
- ▪ Optional occupancy dimming sensor specifically designed to sense motion and illuminate both up and down stairwells (fig 1).
- ▪ Easy installation in new construction or retrofit.
- ▪ cULus listed for damp locations ambient temperatures from
- - 20°C to 50°C (-4°F to 122°F).
- ▪ cULus 1598 and 924 listed.*
- ▪ DLC 5.1 premium approved.
- ▪ Complies with FCC Part 15, class A.
- ▪ Complies with IEEE C.62.41-1991, input transient protection (2.0kV).
- ▪ 5-year warranty of all electronics and housing.
- ▪ Surface Mounting
- * UL 924 listed when used with emergency drivers.
