BL
HOUSING
• Premium powder-coat, aluminum, dark bronze housing.
ELECTRICAL
• Operating temperature (ambient): -40C to 45C (-40F to 113F).
• Universal 120-277V AC voltage (50-60Hz) is standard.
• Input transient surge protection = 4kV.
• Built-in photocell.
• 0-10VDC dimming drivers is standard.
• Power factor >0.90. • Total Harmonic distortion <20%.
OPTICAL SYSTEM
• Polycarbonate frosted lens.
• Field selectable 3000k (warm white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Tri-lumen selectable delivers 3,000 to 4500 nominal lumens*.
• Long-life LEDs provided 151,000 hours of operation with at least 90% of initial lumen output (L90)**.
• Beam angle 3H3V distribution.
• LED color maintenance <-0.00156 chromaticity shift over the initial 6,000 hours of operation.
• Color rendering index > 70.
MOUNTING
• Knuckle mount kit is standard (Fit 1/2" NPT).
• Optional Line Voltage Ground Stake.
• Optional round canopy mount for surface mount. Compatible with 4-inch standard junction box.
• Easy installation in new construction or retrofit.
CODE COMPLIANCE
• cULus listed for wet locations.
• DLC premium listed.
• Complies with FCC part 15, class A.
• IP65 rated for ingress protection.
WARRANTY
• 5 year warranty on all electronics and housing.
HOUSING
• Premium powder-coat, aluminum, dark bronze housing.
ELECTRICAL
• Operating temperature (ambient): -40C to 45C (-40F to 113F).
• Universal 120-277V AC voltage (50-60Hz) is standard.
• Input transient surge protection = 4kV.
• Built-in photocell.
• 0-10VDC dimming drivers is standard.
• Power factor >0.90. • Total Harmonic distortion <20%.
OPTICAL SYSTEM
• Polycarbonate frosted lens.
• Field selectable 3000k (warm white), 4000k (neutral white) and 5000k (cool white) color temperatures.*
• Tri-lumen selectable delivers 3,000 to 4500 nominal lumens*.
• Long-life LEDs provided 151,000 hours of operation with at least 90% of initial lumen output (L90)**.
• Beam angle 3H3V distribution.
• LED color maintenance <-0.00156 chromaticity shift over the initial 6,000 hours of operation.
• Color rendering index > 70.
MOUNTING
• Knuckle mount kit is standard (Fit 1/2" NPT).
• Optional Line Voltage Ground Stake.
• Optional round canopy mount for surface mount. Compatible with 4-inch standard junction box.
• Easy installation in new construction or retrofit.
CODE COMPLIANCE
• cULus listed for wet locations.
• DLC premium listed.
• Complies with FCC part 15, class A.
• IP65 rated for ingress protection.
WARRANTY
• 5 year warranty on all electronics and housing.
